Over 600whp with supporting modifications
The BCP X500R combines a stock-location layout and stock-size inlet with capacity for over 600whp on a properly supported build. Tuning is required.
Specifications
Part number: BCP-500R-010
9-blade billet compressor; 680+ crank-hp maximum-flow rating
Dual-feed hydrostatic bearings with heavy-duty thrust bearing
10cm turbine housing with Subaru EJ flanges
Gaskets and downpipe studs included
Build and installation notes
BCP recommends an IAG closed-deck engine, stock or mildly ported heads, stock cams, a quality front-mount intercooler, equal-length header, 3-inch or larger intake, and E85. For over 600whp on E85, BCP suggests ID1700 injectors and dual fuel pumps.
Do not use an oil restrictor. Internal-wastegate setups may experience boost creep.
Options and warranty
Choose raw aluminum or wrinkle red (Red). Wastegate Yes includes the internal wastegate; No leaves it unwelded; No, Welded Shut adds welding without a wastegate. Optional oil kit fits 2002-2011 WRX / 2004-2021 STI per BCP. A DEI Titanium Turbo Blanket is also available.
BCP provides a one-year, unlimited-mileage warranty on shelf turbochargers. Confirm vehicle fitment before ordering.
